T5
Shat-R-Shield’s vast offering of safety-coated T5 fluorescent lamps provides the ideal option for every lighting need. Whether you’re looking for Philips, Osram Sylvania or our very own etched brand lamps, low wattage, high output or eco-friendly low mercury lamps, Shat-R-Shield’s got you covered.
If a Shat-R-Shield lamp is accidentally broken, virtually all glass, mercury and phosphors are safely contained within the skin tight coating.
The trademarked orange bands applied to every Shat-R-Shield coated fluorescent lamp are the most recognized in the industry for one reason alone — they are the ultimate in protection, time and time again.
The difference lies within the coating method: Zero Gap Technology. Shat-R-Shield lamps go through an extrusion process in which the patented non-yellowing, plastic coating is applied directly onto the lamp, end to end. This creates a skin-tight seal, eliminating any air gaps in which heat from the lamp will become trapped and gradually degrade the coating, leaving the lamp unprotected and your business exposed to the risk of glass breakage. The protective coating is literally one with the lamp; no plastic sleeves, no endcaps and no room for errors.
Shat-R-Shield’s safety coating on fluorescents reduces light output by less than 1%. It is guaranteed not to yellow, crack or flake for the rated life of the lamp. Shat-R-Shield lamps are UL & NSF Certified, USDA approved and meet FDA and OSHA standards.
When considering tubeguards versus a Shat-R-Shield safety-coated lamp, ask yourself — Is the safety of your business, employees, customers, products and yourself something you’re willing to gamble with?
Don’t see the lamp you need? Call Us Immediately
**The safety coating on T5 lamps does not block ultraviolet (UV) light**
-
Documents
-
Video
Watts | Catalog # | Description | Initial Lumens | Mean Lumens | Kelvin Temp | CRI | Length | Base | Hours | Pack By |
---|---|---|---|---|---|---|---|---|---|---|
54.0 | 82570E | F54T5/841/HO/ECO/IC (PK24) | 5000 | 4850 | 4100 K | 86 | 46.00 IN | Miniature Bi-Pin (G5) | 30000 | 24 |
54.0 | 82571E | F54T5/850/HO/ECO/IC (PK24) | 5000 | 4850 | 5000 K | 86 | 46.00 IN | Miniature Bi-Pin (G5) | 30000 | 24 |
54.0 | 82532E | F54T5/850/HO/ECO/IC (PK X 6) | 5000 | 4850 | 5000 K | 86 | 46.00 IN | Miniature Bi-Pin (G5) | 24000 | 6 |
54.0 | 82531E | F54T5/841/HO/ECO/IC (PK X 6) | 5000 | 4850 | 4100 K | 86 | 46.00 IN | Miniature Bi-Pin (G5) | 24000 | 6 |
20.5 | 11030 | FC8T9 CW/PLUS (PK X 12) | 1000 | 850 | 4100 K | 62 | 8.50 IN | G10q | 12000 | 12 |
54.0 | 82582G | F54T5 850/HO/ECO (PK X 40) | 4800 | 4410 | 5000 K | 85 | 46.00 IN | Miniature Bi-Pin (G5) | 36000 | 40 |
54.0 | 82580G | F54T5 835/HO/ECO (PK X 40) | 5000 | 4600 | 3500 K | 85 | 46.00 IN | Miniature Bi-Pin (G5) | 36000 | 40 |
54.0 | 82581G | F54T5 841/HO/ECO (PK X 40) | 5000 | 4600 | 4100 K | 85 | 46.00 IN | Miniature Bi-Pin (G5) | 36000 | 40 |
21.0 | 71541G | F21T5/841/ECO (PK X 40) | 2100 | 1930 | 4100 K | 85 | 34.00 IN | Miniature Bi-Pin (G5) | 36000 | 40 |
49.0 | 82552 | F54T5 841/HO/EA/ALTO 49WATT(PKX40) | 5000 | 4450 | 4100 K | 85 | 46.00 IN | Miniature Bi-Pin (G5) | 30000 | 40 |
49.0 | 82553 | F54T5 850/HO/EA/ALTO 49WATT (PK40) | 4800 | 4275 | 5000 K | 82 | 46.00 IN | Miniature Bi-Pin (G5) | 30000 | 40 |
54.0 | 82558 | F54T5 850/HO/ALTO (PK X 40) | 4800 | 4275 | 5000 K | 84 | 46.00 IN | Miniature Bi-Pin (G5) | 24000 | 40 |
28.0 | 73520 | F28T5 830/ALTO (PK X 40) | 2900 | 2625 | 3000 K | 83 | 46.00 IN | Miniature Bi-Pin (G5) | 24000 | 40 |
28.0 | 73538 | F28T5 835/ALTO (PK X 40) | 2900 | 2625 | 3500 K | 82 | 46.00 IN | Miniature Bi-Pin (G5) | 24000 | 40 |
13.0 | 13010 | F13T5 CW (PK X 25) | 930 | 655 | 4100 K | 60 | 21.00 IN | Miniature Bi-Pin (G5) | 8000 | 25 |
54.0 | 82548 | F54T5 841/HO/ALTO (PK X 40) | 5000 | 4450 | 4100 K | 85 | 46.00 IN | Miniature Bi-Pin (G5) | 24000 | 40 |
21.0 | 71530 | F21T5/835/ALTO (PK X 40) | 2100 | 1925 | 3500 K | 85 | 34.00 IN | Miniature Bi-Pin (G5) | 24000 | 40 |
14.0 | 79520 | F14T5 830/ALTO (PK X 40) | 1350 | 1250 | 3000 K | 83 | 22.20 IN | Miniature Bi-Pin (G5) | 24000 | 40 |
21.0 | 71540 | F21T5/841/ALTO (PK X 40) | 2100 | 2000 | 4100 K | 85 | 34.00 IN | Miniature Bi-Pin (G5) | 24000 | 40 |
35.0 | 77540 | F35T5 841 (PK X 40) | 3650 | 3450 | 4100 K | 85 | 58.00 IN | Miniature Bi-Pin (G5) | 35000 | 40 |
28.0 | 73540 | F28T5 841/ALTO (PK X 40) | 2900 | 2750 | 4100 K | 82 | 46.00 IN | Miniature Bi-Pin (G5) | 35000 | 40 |
54.0 | 82537 | F54T5 835/HO/ALTO (PK X 40) | 5000 | 4450 | 3500 K | 85 | 46.00 IN | Miniature Bi-Pin (G5) | 24000 | 40 |
39.0 | 87547 | F39T5/841/HO (PK X 40) | 3500 | 3100 | 4100 K | 85 | 34.00 IN | Miniature Bi-Pin (G5) | 24000 | 40 |
39.0 | 87527 | F39T5/830/HO (PK X 40) | 3500 | 3100 | 3000 K | 85 | 34.00 IN | Miniature Bi-Pin (G5) | 24000 | 40 |
24.0 | 80537 | F24T5 835/HO/ALTO (PK X 40) | 1950 | 1850 | 3500 K | 85 | 22.00 IN | Miniature Bi-Pin (G5) | 35000 | 40 |
24.0 | 80547 | F24T5 841/HO/ALTO (PK X 40) | 1950 | 1850 | 4100 K | 85 | 22.00 IN | Miniature Bi-Pin (G5) | 35000 | 40 |
14.0 | 79540 | F14T5 841/ALTO (PK X 40) | 1350 | 1250 | 4100 K | 82 | 22.20 IN | Miniature Bi-Pin (G5) | 24000 | 40 |
35.0 | 77520 | F35T5 830 (PK X 40) | 3650 | 3450 | 3000 K | 85 | 58.00 IN | Miniature Bi-Pin (G5) | 24000 | 40 |
21.0 | 71520 | F21T5/830/ALTO (PK X 40) | 2100 | 2000 | 3000 K | 85 | 34.00 IN | Miniature Bi-Pin (G5) | 24000 | 40 |
